Conveyor accessories

There is much more to a good conveyor than the belt and frame

A conveyor is so vital to operations that it is sometimes described as ‘the main artery’. When conveying is not working, your mine, quarry or construction site can’t run properly either. It makes sense to employ every possible measure to protect your conveyor and avoid unscheduled conveyor stoppages – whether they are caused by a dusty environment, material spillage or impact damage. Loss of material and work stoppages not only mean a loss of revenue but move you further away from your sustainability goals. Metso's conveyor accessories are engineered to keep your equipment and business running smoothly without unexpected downtime while helping you to meet your objectives.
Versatility

The most complete product range on the market to maximize output and safety of your conveyor operations.

One-stop partner

Dedicated to keeping your operation as productive and profitable as possible.

Sustainability

Durable conveyor parts designed for long component life.

Reduced downtime

Smart, simple design that makes parts efficient, robust and maintenance friendly.

360°

View 3D models

Have a closer look at our accessories by exploring the 3D models library. Zoom in, rotate and see every detail!

Click "+" on the Accessories 3d models bar and view 3D models.

View 3D models

360°

Trellex ABC-ONE70

Installation:

Belt speed: < 3.5 m/s

Head pulley diameter: 300 mm – 600 mm

Belt width: 300 mm – 1,800 mm (12” – 72”)

Trellex ABC-ONE70

360°

Trellex ABC-ONE90

Installation:

Belt speed: < 3.5 m/s

Head pulley diameter: 300 mm – 600 mm

Belt width: 300 mm – 1,800 mm (12” – 72”)

Trellex ABC-ONE90

360°

Trellex ABC70

Installation:

Belt speed: < 3.5 m/s

Head pulley diameter: 350 mm – 600 mm

Belt width: 500 mm – 3,000 mm (24” – 120”)

Trellex ABC70

360°

Trellex ABC90

Installation:

Belt speed: < 3.5 m/s

Head pulley diameter: 350 mm – 600 mm

Belt width: 500 mm – 3,000 mm (24” – 120”)

Trellex ABC90

360°

Trellex ABC95

Installation:

Belt speed: < 3.5 m/s

Head pulley diameter: 350 mm – 600 mm

Belt width: 500 mm – 3,000 mm (24” – 120”)

Trellex ABC95

360°

Trellex ABC-HMS

Installation:

Belt speed: < 3.5 m/s

Head pulley diameter: 350 mm – 800 mm

Belt width: 500 mm – 3,000 mm (24” – 120”)

Trellex ABC-HMS

360°

Trellex ABC70-HD

Installation:

Belt speed: < 4.5 m/s

Head pulley diameter: 600 mm – 1,000 mm

Belt width: 500 mm – 3,000 mm (24” – 120”)

Trellex ABC70-HD

360°

Trellex ABC90-HD

Installation:

Belt speed: < 4.5 m/s

Head pulley diameter: 600 mm – 1,000 mm

Belt width: 500 mm – 3,000 mm (24” – 120”)

Trellex ABC90-HD

360°

Trellex ABC70-HD-L

Installation:

Belt speed: < 6 m/s

Head pulley diameter: 800 mm – 1,600 mm

Belt width: 600 mm – 3,000 mm (24” – 120”)

Trellex ABC70-HD-L

360°

Trellex ABC90-HD-L

Installation:

Belt speed: < 6 m/s

Head pulley diameter: 800 mm – 1,600 mm

Belt width: 600 mm – 3,000 mm (24” – 120”)

Trellex ABC90-HD-L

360°

Trellex ABC90-HD-XL

Installation:

Belt speed: < 6 m/s

Head pulley diameter: 1,000 mm – 2,000 mm

Belt width: 700 mm – 3,000 mm (30” – 120”)

Trellex ABC90-HD-XL

360°

Trellex ABC-T HS RU

Installation:

Belt speed: < 3.5 m/s

Belt width: 500 mm – 2,000 mm (24” – 84”)

Trellex ABC-T HS RU

360°

Trellex ABC-T HMS RU

Installation:

Belt speed: < 3.5 m/s

Belt width: 500 mm – 3,000 mm (24” – 120”)

Trellex ABC-T HMS RU

360°

Trellex ABC-T HMS PU

Installation:

Belt speed: < 3.5 m/s

Belt width: 500 mm – 3,000 mm (24” – 120”)

Trellex ABC-T HMS PU

360°

Trellex ABC-U-HMS

Installation:

Belt speed: < 5 m/s

Belt width: 500 mm – 2,000 mm (24” – 84”)

Trellex ABC-U-HMS

360°

Trellex ABC-Arm

Installation:

Belt speed: < 3.5 m/s

Belt width: 500 mm – 3,000 mm (24” – 120”)

Trellex ABC-Arm

360°

Trellex ABC-T HMS-HD-L

Installation:

Belt speed: < 5 m/s

Belt width: 750 mm – 3,000 mm (30” – 120”)

Trellex ABC-T HMS-HD-L

360°

Trellex ABC-BRUSH

Installation:

Belt speed: < 2.5 m/s (< 500 fpm)

Belt width: 500 mm – 1,800 mm (24” – 72”)

Belt direction: One way

Trellex ABC-BRUSH

360°

Trellex ABC-V-Plow

Installation:

Belt speed: < 5 m/s

Belt width: 500 mm – 2,400 mm (18” – 96”)

Belt direction: One way

Trellex ABC-V-Plow

360°

Trellex ABC-Easy

Dimension: 25 mm x 130 mm (1” x 5.1”)

Length: 500 mm, 1,000 mm, 1,500 mm & 2,000 mm

(20”, 40”, 60” & 80”)

Trellex ABC-Easy

360°

Trellex ABC-MC-LT

Installation:

Suitable for all mobile Metso Lokotracks

Trellex ABC-MC-LT

360°

ABC-LT Cleaner kit

Installation:

Suitable for all mobile Metso Lokotracks

ABC-LT Cleaner kit

360°

Trellex SBC

Installation:

Belt speed: < 2,5 m/s

Belt direction: One way

Trellex SBC

360°

Trellex SBC-HD

Installation:

Belt speed: < 4 m/s

Belt direction: One way

Trellex SBC-HD

360°

Trellex SBG

Installation:

Belt speed: < 6 m/s

Belt direction: One way

Trellex SBG

360°

Trellex TBG

Installation:

Belt speed: < 6 m/s

Belt direction: One way

Trellex TBG

360°

Trellex RBC

Installation:

Belt speed: < 2,5 m/s

Belt direction: Reversible

Trellex RBC

360°

Trellex RBG

Installation:

Belt speed: < 6 m/s

Belt direction: Reversible

Trellex RBG

360°

Trellex Impact Cradle

Installation: Light to heavy-duty applications

To confidently choose a loading solution, use Trellex Impact Calculator.

Trellex Impact Cradle

360°

Trellex Impact Bar

Available in many different sizes

Trellex Impact Bar

360°

Trellex Glide Bar Cradle

Installation:

Belt width: 500 mm – 1,200 mm (18” – 48”)

Trellex Glide Bar Cradle

360°

Trellex Snap-On

Installation: Light to medium duty applications

Length: 2,400 mm (Both sides incl.)

Trellex Snap-On

360°

Trellex Clamp-On

Installtion: Light to medium duty applications

Length: 1,200 mm (Both sides included)

Trellex Clamp-On

360°

WAMskirt

Installation: Medium to heavy-duty applications

Length: 1200mm, 1500mm, 1800mm (4ft, 5ft & 6ft)

Other lengths ETO

WAMskirt

360°

Trellex Safety Hatch

Dimensions: 400 mm x 325 mm

(15.7” x 12.8”)

Trellex Safety Hatch

360°

Trellex Pulley Bar

Installation: Medium to heavy duty applications

Bolted

Trellex Pulley Bar

360°

Trellex Griplag

Installation: Light to medium duty applications

Bolted

Not suitable on reversible belts

Trellex Griplag

360°

Traclag

Installation:

Cold bonding rubber lagging

(Hot vulcanized available on request)

Fire resistant & Anti static FRAS (available on request)

Traclag

360°

360°

Cerlag

Installation:

Drive & Non-drive pulley

Cold bonding rubber/ceramic lagging

(Hot vulcanized available on request)

Fire resistant & Anti static FRAS (available on request)

Cerlag

360°

Cerlag ceramic pulley bar

Installation: Bolted to pulley surface



Cerlag ceramic pulley bar

360°

Installation: Directly to the pulley shell

360°

360°

PUlag

Installation:

Non-drive pulley

Cold bonding polyurethane lagging

(Hot vulcanized available on request)

PUlag

360°

HiSafe Head Pulley Guard

Installation:

Belt width: 500 mm – 1,400 mm (24” – 60”)

Head pulley diameter: < 650 mm

HiSafe Head Pulley Guard

360°

HiSafe End Pulley Guard

Installation:

Belt width: 500 mm – 1,200 mm (24” – 48”)

HiSafe End Pulley Guard

360°

Torque-Master™ Holdbacks

Installation:

Bore range: 60 mm – 465 mm (2.4” – 18.3”)

Torque capacity: 6,760 – 980,000 Nm

Torque-Master™ Holdbacks
